testo 616 – Material Moisture Meter
Product Descriptions
The test 616 allows fast and damage-free examination of material moisture curves in building materials and woods. It also facilitates your work in observing the drying process of floors walls and surfaces. For especially fast and easy handling, characteristic curves are stored for anhydrite screed, cement screed, lime sand brick, aerated concrete, concrete, vertical hole brick and solid brick for detecting wet spots in building materials. For the measurement of wood moisture, characteristic curves are available for soft woods, hard woods and chipboard. These characteristic curves were developed in cooperation with the LPI institute.
The measurement results are recorded to a depth of up to 5 cm and can be frozen at the press of a button. The display is in percentage by weight related to the dry mass of the material. The testo 616 also reliably supports you in the determination of the point in time and the place for any necessary destructive measurements.
T• Measures the moisture content of wood and building materials quickly and reliably
• Non-destructive, precise measurements up to a material depth of 5 cm
• 10 characteristic curves for different types of building material and wood
• Backlit display, hold function, min/max memory, ergonomic design
TThe testo 616 professional moisture meter provides you with a precise and non-destructive means of measuring the moisture content of wood and other building materials.
Technical Data | |
General technical data | |
Dimensions | 70 x 58 x 234 mm |
Operating temperature | +5 to +40 °C |
Product-/housing material | ABS / TPE / Metal |
Protection class | IP30 |
Battery type | 9V block battery, 6F22 |
Battery life | 60 h |
Display update | 0.5 s |
Unit | Water content in percent by weight based on dry mass (%) |
Measurement depth | up to 5 cm |
Measuring rate | 0.5 s |
Storage temperature | -20 to +70 °C |
Weight | 260 g |
Humidity – Capacitive | |
Measuring range | < 50 % (wood) |
< 20 % (building materials) | |
Resolution | 0.1 |
