testo 176-T2 Temperature data logger
Product Description
The testo 176 T2 temperature logger is particularly suitable for reliable temperature monitoring on two channels. The data logger can accommodate two Pt100 probes of your choice, which you can order from our probes range. It is therefore possible to safely store temperature values from different measuring locations and, if required, compare them on site on the logger display.
You can carry out temperature monitoring over a longer period of time (eliminating the need for the data logger to be read out overly frequently). The testo 176 T2 temperature logger can store up to 2 million readings. Its battery life of up to 8 years also makes it practical for long-term temperature monitoring.
• Ideal for long-term measurements: memory for up to 2 million readings, up to 8 years’ battery life
• High-precision measurements with Pt100 probes: connections available for 2 external probes
• Certified according to EN 12830, HACCP-compliant and waterproof in compliance with IP 65
• Three software versions available for data management on the PC, basic software available as a free download
With its two inputs for external Pt100 probes, the testo 176 T2 temperature logger can record the temperature at two measuring points simultaneously. This makes it possible to monitor temperature at different locations in parallel. The data logger features a large display for optimum presentation of the readings.
Technical features and practical benefits
The logger display offers you an overview of the current readings, limit values set and limit value violations, minimum and maximum values and also the remaining battery life. Thus, there is no need to read the data logger separately on your PC in order to quickly check it.
Data security is our top priority: you can rest assured that the measurement data stored in the temperature logger will not be lost. Data is not lost, even when the logger’s battery is spent or while you are changing it.
The temperature logger is suitable for use in the food industry: it is certified to EN 12830 (tested by the ATP test station at TÜV Süd) and is HACCP-compliant. In compliance with protection class IP 65, the data logger is protected against water jets and can remain at the measuring location while cleaning is carried out there.
Technical Data | |
Temperature – Pt100 | |
Measuring range | -100 to +400 °C |
Accuracy | ±0.2 °C (-100 to +200 °C) ±1 Digit |
±0.3 °C (+200.1 to +400 °C) ±1 Digit | |
Resolution | 0.01 °C |
General technical data | |
Weight | 220 g |
Dimensions | 103 x 63 x 33 mm |
Operating temperature | -35 to +70 °C |
Product-/housing material | Plastic |
Protection class | IP65 |
Channels | 2 external |
Connectable probes | 2 x Pt100 temperature probe |
Product colour | white |
Standards | EU-guideline 2014/30/EU; 2011/65/EU; DIN EN 12830 |
Measuring rate | 1 s to 24 h; 2 s to 24 h (online measurement) |
Battery type | 1 x Lithium (TL-5903) |
Battery life | 8 years (15 min. meas. rate, +25 °C) |
Interface | mini usb, SD card slot |
Memory | 2,000,000 measuring values |
Storage temperature | -40 to +85 °C |
